HYPER Series
OmniGate's HYPER series is a System-on-Chip (SoC) designed for edge computing and AI applications. It offers powerful AI performance (8 TOPS INT8), efficient GPU (200+ GFLOPS), and supports 4K video, multi-display output, and hardware cryptography. Its applications are wide-ranging, covering smart cockpits, AIoT terminals, and smart cameras, providing a comprehensive solution integrating processing, graphics, AI, and security features.
Key Performance Indices
8 TOPS AI Performance with INT8 compute
200+ GFLOPS GPU for advanced graphics rendering
4K video decode and multi-display output support
Secure edge computing with on-chip hardware cryptography
Target Applications
Smart Dash / Automotive Cockpits
Premium AITerminals / Edge AI Devices
Vision-based Smart Cameras
AIoT Hubs / Voice Assistants
Hyper Series
Computing
System
CPU
RISC-V, 4-8x Performance cores (2.2–2.4GHz) + 2-4x Efficiency cores (1.5–1.8GHz)
GPU
200+ GFLOPS FP32, OpenGL ES 3.2 and Vulkan 1.2 capable
AI
5-8 TOPS (INT8), 2+ TOPS (FP16)
DSP
Dual-core, capable of 1 TOPS CV pre-processing or 200 GOPS audio DSP
Memory & Storage
LPDDR4X / LPDDR5, 32-bit interface, up to 8GB
UFS 2.1 or eMMC 5.1
Multi-Media
Video Codec : 4K@30fps decode (H.265/H.264), 1080p@30fps encode
I/O Interfaces
PCIe Gen3 x1, USB 3.1/3.2, MIPI-CSI/DSI (4+4 lanes), SDIO, I²S, I²C, SPI
Display
Up to 2560×1600 @ 60Hz, or FHD+ @ 90Hz (Dual Panel capable)
Security
Secure Boot, AES-256, SHA-2, hardware RNG, eFuse
